Q941F-16Q/25Q electric ball valve

[Product Description] Q941F-16Q and Q941F-25Q electric iron ball valves: electric drive, flange connection, floating ball through type, valve seat sealing surface material is fluoroplastic, nominal pressure PN16~PN25, nominal size DN20~DN200, and valve body material is ductile iron ball valves. The Q941F-16Q and Q941F-25Q electric iron ball valves are suitable for two position cut-off and adjustment situations. The connection between the valve and the actuator adopts a direct connection method. The electric actuator is equipped with a servo system, without the need for an additional servo amplifier. The operation can be controlled by inputting a 4-20mA signal and a 220VAC power supply. It has the advantages of simple connection, compact structure, small size, light weight, low resistance, and stable and reliable operation. The actuator can be configured with different models of electronic electric actuators or pneumatic piston actuators according to user requirements.Wenzhou Tielong Va…
